WORLDPRESS JH25
Potencia de precisión. Diseño que inspira confianza.
The World JH25-160 is a C-frame, double-crank mechanical press with a capacity of 160 tons (≈ 1600 kN) . It is designed for progressive stamping, punching, and forming of large sheet metal, with high structural rigidity and modern control (PLC + display), ideal for demanding industrial production.
Especificaciones técnicas
| Especificación | Valor |
|---|---|
| Nominal capacity (Pe) | 1600 kN / 160 tons |
| Slider stroke (Stroke Length, S) | 200 mm |
| Fixed SPM | 45 strokes per minute |
| Optional Variable Speed | 35-55 SPM |
| Maximum closing height / die height (Max Die Shut Height H₂) | 450 mm |
| Die Height Adjustment | 100 mm |
| Throat Depth (G) | 390 mm |
| Distance between columns (Between Uprights / N) | 1600 mm |
| Table/bolster size (Front-Bottom × Length-Right) | 760 × 2040 mm |
| Table thickness (Bolster Thickness) | 165 mm |
| Slide Bottom Size | 580 × 1500 mm |
| Table height to floor (Bolster Surface Height H₁ | ) 900 mm |
| Approximate external dimensions | 2080 × 2150 × 3380 mm (FB × LR × Height) |
| Main engine power | 18.5 kW |
| Estimated weight | 19,000 kg |
Equipamiento de la Máquina:
Estándar
- Wet type pneumatic clutch and brake
- PLC + HMI control (touch screen)
- Hydraulic overload protection system
- Centralized automatic lubrication (“auto grease / auto lube lubrication”)
- Six-face rectangular slide guideways
¿Interesado en esta máquina?
- ✅ Wide table for progressive dies
- ✅ Solid welded C-type structure
- ✅ PLC control with touch screen
- ✅ Durable, quiet wet-pneumatic clutch
- ✅ Hydraulic overload protection
